Low noise design
Aluminum inner/outer tube
Good Moldeling/Easy to install
Lubrication for longer life time

Input Voltage : DC 24V
Load Capacity : 800N
Speed at No Load : 10mm/sec
Stroke :50/150/200/300/400mm
Stroke Tolerance : ±1mm
Operation Temp. : -26℃~65℃
Limit Switch : Built-in
Gear Ratio : 30:1
Static Load : 2300N
Screw : ACME
Clevis Ends : ￠8.1
Duty Cycle : 25%
IP Grade : IP66
Noise value : 60dB
