Housing
- Patent design for assembling the tube & good quality consistency
- Slim surface for easy clean and maintenance
- TMP210 can handle a great bending moment, 5 Step aluminum body.
Gear box
- Die-Casting gear box for strong supporting to motor shaft."
Spindle
- Safety nut & Quick Release available
- Multi combination for different load & speed
- Limit switch built in
- Manual release/lowering(Q4, 2010)
Motor
- In-house made motor
- High resolution hall sensor available
Potentiometer, Optical sensor, Reed sensor
- Duty cycle: 10% max. or 2 min. continuous use followed by 18 min. not in use"
Control
- Instinctive control, synchronized movement when an uneven load on the desk.
- Driven by 24VDC motor system, achieve quiet and safe operation.
- 3 Step Memory position for individual users.
- Synchronized operation for max 6 columns.
|
